Specifications
Web slings made with a flat loop eye on each end with loop eye opening on same place as sling body. This type of sling is sometimes called a flat eye and eye, eye and eye, or double eye.
| PLY | WEB WIDTH | VERTICAL RATED CAPACITY (LBS.) | CHOKER RATED CAPACITY (LBS.) | BASKET RATED CAPACITY (LBS.) | PRODUCT CODE |
| TWO PLY | 1″ | 3,200 | 2,560 | 6,400 | EE2-901 |
| 2″ | 6,400 | 5,120 | 12,800 | EE2-902 | |
| 3″ | 9,600 | 7,680 | 19,200 | EE2-903 | |
| 4″ | 12,800 | 10,240 | 25,600 | EE2-904 |
Note: Twisted Eye Slings retain the same rated capacity as Flat Eye Slings.
Note: All slings and bridles can be fitted with wear pads and sleeves.
Warnings
- No product can operate indefinitely at its rated capacity.
- Avoid shock loads and side loads.
- Keep out from under a raised load.
- Never exceed the Working Load Limit.
- Inspect your rigging products regularly.
